Application
Rated current: 16 a (2.5 was AWG14), 30 (4 was AWG12), 52 a (6 was, AWG10)
Conventional current rating: 30A
Withstand voltage: DC1000V
Contact resistance: 2 m Ω
Insulation resistance: > 500 m Ω
For single core cable: 2.5 was, was 4, 6 was or 14 awg, 12 awg, 10 awg
Φ 5 mm 7 mm
Ambient temperature: 40 ~ 105
Protection grade: IP67
Shell: TPU
Contact: copper CN, tin plating SN
Connection mode: pressure welding
Lock system: embedded
