Features
1) A wide selection of models suited to many applications ( 3 and 4 poles from 63 to 1250 A)
2) High breaking capacities with four performance levels from 10 kA to 100 kA
3) Fewer frame sizes: just two pole pitches for easy integration in installation systems (enclosure, machines, etc.)
4) Accessories for insulation and series or parallel connection of pole, suited to the particularities of DC applications
Pole of number 1P 2P 3P 4P
Rated current(A) 6 10 16 20 25 32 40 50 63
Rated operation voltage(V DC) 250 500 750 1000
Rated insulation voltage Ui(V DC) 1000V
Rated inpluse withstand voltage 4000
Ultimate breaking capacity 6000
Curve type B C
Mechanical endurance 10000 cycles
Electrical endurance 2000 cycles
Specification
