Operation current: 16A
Operation power voltage: 100~240V AC
Allowable erating voltage: 85~264V AC
Power source frequency: 50Hz/60 Hz common use
Driving method: Quarts motor
Power failre compensation: 100hours(battery built-in)
Time precision: with±15 seconds per month(at temperature 25°C)
Program cycle: 24 hours
Consumption power: 110V AC 1W 220VAC2W
Power Failure Compensating Time
This time switch is equipped with a built-in battery to work in service interruption.
1.When turned on the time switch, the battery is to be charged automatically.
2.The battery is charged fully to be able to compensate power failure for 300 hours when supplied power.
3.days in succession.
4.Frequent power failure and service interruption for a long time will shorten the life span of the storage battery.
So please take care.
