Description:
- Staircase time switch, electronic
- Automatic 3 or 4 conductor detection(4 conductor with connection for fl oorlighting)
- Retriggerable
- Extended function activated via long button press.
- Toggle switch for permanent light ON
- Simplest possible time setting and direct delay time readout on absolutescale
- Immediate secondary switching
Technical Data:
| Operating voltage | 220–240 V AC |
| Frequency | 50–60 Hz |
| Width | 1 module |
| Power consumption | 1 VA |
| Setting range | 0.5–20 min |
| 3/4 conductors | Automatic |
| Type of contact | NO contact |
| Switch output | Non-floating (230 V) |
| Incandescent lamp load | 3600 W |
| Flourescent lamp load lead-lag circuit | 3600 VA |
| Flourescent lamp load parallel-corrected | 1200 VA, (120 μF) |
| Compact energy saving lamps | 34 x 7 W, 27 x 11 W, 24 x 15 W, 22 x 23 W 9 x 7 W, 7 x 11 W, 7 x 15 W, 7 x 20 W, 7 x 23 W |
| Switching capacity | 16 A (at 230 V AC, cos φ = 1) 10 A (at 230 V AC, cos φ = 0.6) |
| Ambient temperature | –10 °C … +55 °C |
| Protection class | II in accordance with EN 60 730-1 |
| Protection rating | IP 20 |
